Horizontal communication basic hydraulic power unit

1、 Product Overview

This is a basic horizontal AC hydraulic power station that integrates an aluminum shell AC motor, a high-pressure gear pump, an oil circuit integrated valve block, and a horizontal circular steel oil tank. It reserves a valve position for solenoid valve installation and is compatible with AC220V single-phase/AC380V three-phase industrial mains power. Single/dual electromagnetic directional valves can be installed as needed. It is commonly used for fixed industrial hydraulic equipment such as small lifting platforms, boarding bridges, auto repair tire removal machines, and assembly line lifting fixtures. It is a highly versatile standard hydraulic oil supply assembly.

2、 Core structural components

Aluminum shell AC industrial motor

Integrated aluminum alloy heat dissipation body, fully covered with heat dissipation fins, low temperature rise during long-term continuous operation; Square sealed junction box with high voltage warning label, protection level IP54, dust-proof and splash proof, suitable for workshop environments with high dust and humidity; Reserved bare wire terminals for motor output, convenient for on-site wiring, low vibration and noise during operation, and stable and long-lasting power output.

Standard integrated oil circuit valve block

Precision forged aluminum alloy valve block, reserved standard electromagnetic directional valve installation holes, inlet and outlet ports, built-in overflow pressure regulating valve, can uniformly adjust the maximum working pressure of the system, overload automatic pressure relief protection pipeline oil cylinder; No extra external connectors, greatly reducing the risk of leakage, and flexible installation of single or dual electromagnetic reversing components.

High pressure wear-resistant gear pump

High precision aluminum alloy gear pump, high volumetric efficiency, rated working pressure up to 16MPa, uniform and stable oil supply, wear-resistant and anti leakage, no significant attenuation of oil pressure when lifting loads, suitable for small and medium-sized clamping and lifting conditions.

Horizontal circular thickened steel fuel tank

One piece welded cylindrical cold-rolled steel plate oil tank, black anti-corrosion paint, resistant to pressure and impact, not easily deformed; The top red explosion-proof breathable oil cap balances the air pressure inside the oil tank and facilitates the filling of hydraulic oil; The circular horizontal layout saves vertical installation space for equipment, with an integrated metal base at the bottom, and the whole machine is firmly fixed and shock-absorbing.

3、 Core advantages of the product

✅  Basic universal version, suitable for most small industrial equipment

Reserve standard valve positions and freely choose single/dual solenoid valves. One host can adapt to various lifting and clamping equipment, with strong versatility and lower stocking costs.

✅  Exchange industrial power supply, support long-term continuous operation

Adapt to the fixed mains power supply of the factory, distinguish from the on-board DC pump station, and meet the continuous operation needs of the assembly line for 24 hours.

✅  Steel circular fuel tank is sturdy and resistant to construction

Thickened steel plates are resistant to vibration and bumps, and compared to plastic fuel tanks, they are more resistant to high temperatures and have no risk of aging or cracking. The anti rust coating prevents rust residue from blocking the oil circuit.

✅  Aluminum shell motor has excellent heat dissipation and longer service life

The all aluminum body quickly dissipates heat, making it less likely to burn out coils after long-term operation. The sealed junction box is suitable for harsh workshop conditions.

✅  Flexible non-standard customization

Support customized motor power of 0.75~3kW, fuel tank capacity of 3-8L, installation of pressure gauge, single/dual electromagnetic reversing, and manual emergency descent function.

4、 Typical application scenarios

Auto repair equipment: tire scraping machine, small lift, hydraulic clamping fixture

Logistics and warehousing: fixed boarding bridge, small cargo lifting platform, storage lifting column

Automated assembly line: material lifting fixture, small hydraulic press fitting machine

Small non-standard machinery: simple bending and punching hydraulic equipment

Venue supporting facilities: small lifting stage, hydraulic system for lifting basketball hoop

5、 Standard technical parameters

Supply voltage: AC220V single-phase/AC380V three-phase

Motor power: 0.75kW/1.1kW/1.5kW/2.2kW/3kW optional

Rated working pressure: 8-16MPa (adjustable for the entire machine)

Fuel tank material: Cold rolled steel plate anti-corrosion paint

Fuel tank capacity: 3L, 4L, 5L, 8L optional

Additional features: Can be equipped with single/dual electromagnetic directional valves, pressure gauges, and manual pressure relief

Applicable medium: 46 # anti-wear hydraulic oil

Installation form: Horizontal base fixed with bolts

6、 Instructions for Use and Maintenance

Add 46 # anti-wear hydraulic oil to the standard oil level mark of the oil tank, and tighten the red breathable oil cap;

After assembling the solenoid valve as needed, connect the hydraulic oil pipe and tighten the joint to prevent leakage;

Standardize the wiring of the motor and ensure proper grounding protection. After confirming that the motor direction is correct, conduct a no-load test run;

Set the working pressure of the overflow valve according to the load regulation, and prohibit long-term use beyond the rated pressure;

Check the cleanliness of hydraulic oil every 300 hours, and replace it promptly if the oil is cloudy or contains impurities.

7、 After sales guarantee

Factory stock direct delivery, supporting non-standard customization of power, fuel tank capacity, and valve group configuration, providing wiring drawings, installation and commissioning technical guidance; The whole machine is guaranteed for 12 months, and the motor, pump body, and valve block accessories are supplied for long-term matching. Remote troubleshooting is available, and a complete set of hydraulic solutions for matching oil cylinders and oil pipes can be purchased in bulk.
