Power Unit for All-Electric Stackers

The Rohn Hydraulic's Power Unit for All-Electric Stackers is a crucial component that provides the necessary hydraulic power for the lifting, lowering, and maneuvering functions of these material handling vehicles. Let's delve into the detailed description of this product, including its scope of use, typical applications, operation methods, product specifications, and additional information.

Scope of Use:

The Rohn Hydraulic's Power Unit for All-Electric Stackers is designed to be used in various industrial and commercial settings where efficient material handling is required. It is suitable for warehouses, distribution centers, manufacturing facilities, logistics operations, retail stores, and other environments where palletized goods need to be transported, stacked, or retrieved.

Typical Applications:

This Rohn Hydraulic's Power Unit for All-Electric Stackers is commonly employed in fully electric pallet trucks, also known as fully electric stackers, which are used for loading, unloading, and transporting palletized goods within warehouses and other storage facilities. It enables the smooth and precise lifting and lowering of loads, as well as the movement of the truck in different directions.

Operation Methods:

The Rohn Hydraulic's Power Unit for All-Electric Stackers operates by receiving electrical signals from the vehicle's control system, which trigger the activation of hydraulic components such as the pump, motor, valves, and cylinders. These components work together to generate hydraulic pressure, which is then transmitted to the lifting mechanism of the pallet truck to raise or lower the load as needed. The operator controls the movement of the vehicle using a joystick or other control interface.

Product Specifications:

Power Source: Electric motor

Voltage: Typically 24V or 48V DC

Pump Type: Gear pump or piston pump

Maximum Pressure: Up to 250 bar (3625 psi)

Flow Rate: Variable, depending on the application

Reservoir Capacity: Typically 5 to 20 liters (1.3 to 5.3 gallons)

Control System: Electrically controlled valves and sensors

Protection: Overload protection, temperature protection, and emergency stop features

Additional Information:

Materials: Constructed with durable materials such as steel, aluminum, and engineering plastics to ensure robustness and longevity.

Safety Features: Equipped with safety features such as emergency stop buttons, tilt sensors, and load weight sensors to prevent accidents and ensure operator safety.

Maintenance: Regular maintenance and inspection are essential to ensure the proper functioning of the hydraulic power unit. This includes checking fluid levels, inspecting hoses and connections for leaks, and lubricating moving parts as needed.

In summary, the Rohn Hydraulic's Power Unit for All-Electric Stackers plays a crucial role in enabling the efficient and safe operation of material handling equipment in various industrial and commercial settings. Its robust construction, precise control, and safety features make it an indispensable component for optimizing warehouse and logistics operations.

This power unit is specially designed for electric stacker,It is a typical power ascending and gravity descending system,whose descending speed is automatically controlled by built- -in pressure compensating throttle valve.

Model Specifications

Special Notes

1. For different flow rate pump, pressure and motor power, please check the ordering guidance.
2. This motor is based on gap working system S2=2 ~ 4min(continuous working time), so it cannot run continuously.
3. Before installation, the cylinder, oil pipe, joint and other hydraulic components must be cleaned and free from any impurities.
4. The viscosity of hydraulic oil should be 15- -68cst and should be clean and free of impurities .HM46 hydraulic oil is recommended.
5. If you need manual oil discharge device for emergency , please specify when ordering.
6. Check that whether there is enough oil in the oil tank immediately after the first operating of the system.
7. The hydraulic oil should be replaced after the first 100 hours' use of the system, and change the oil every 3,000 hours after that.
