Electric basketball hoop power unit

1. Precise and smooth driving

Independent dual hydraulic circuits control the lifting and lowering of the basket frame and the ascent and descent of the traveling wheels, respectively, ensuring non-interference during operation

Equipped with a pressure compensation balance valve, it descends at a steady speed without impact, eliminating shaking and abnormal noise

Height adjustment range: 1.6m–3.05m, positioning error: ≤±2mm, precisely locks to FIBA standard height

II. Safe and reliable design

Triple safety mechanisms including overload protection, pressure relief protection, and anti-fall protection ensure a more secure operation

The sealing component is oil-proof, resistant to high and low temperatures, anti-aging, and has no leakage after long-term use

Pure copper motor + high-strength integrated valve block, stable load-bearing capacity, and less prone to damage from frequent start-stop operations

III. Convenient and Intelligent Operation

Supports both panel control and wireless remote control modes, with one-button lifting and one-button wheel retracting

220V regular mains power access, ready to use upon installation, no complex modification required

Compact in size and easy to install, it can be matched with most brands of electric basketball hoops

IV. Durable and Long-lived

Thickened fuel tank + anti-rust treatment, corrosion-resistant and impact-resistant

The core components operate stably and continuously, meeting the high-frequency usage demands of the venue

Easy to maintain, requiring only regular checks on the oil level for daily use, thereby reducing operational costs

Technical parameters (regular model)

Motor power: 0.75KW/1.5KW (optional)

Operating voltage: AC220V/50Hz

System pressure: 16–20MPa

Control mode: electromagnetic reversing + wireless remote control

Fuel tank capacity: 5L/8L

Compatible with: Indoor electric hydraulic basketball stands, folding mobile basketball stands

Applicable scenarios

Professional sports venues, event centers

Primary and secondary schools / university gymnasiums, training centers

Community fitness center, commercial cultural and sports space

Multi-functional indoor court, movable game basket stand
